Description

Features:

Monopolar CUT:
” PURE CUT : 480 Khz sinusoid, 300 W @ 300 E
” BLEND1 : 480 Khz sinusoid with 70% duty cycle, 250 W @ 300 E
” BLEND2 : 480 Khz sinusoid with 55% duty cycle, 200 W @ 300 E

Monopolar COAG:
” SPRAY : 480 KHz sinusoid bursts, 120 W @ 500 E
” FULGURATE : 480 KHz damped sinusoid bursts, 150 W @ 500 E
” DESICCATE : 480 Khz sinusoid with very low max. Voltage, 80 W @ 500 E

BIPOLAR:
” MICRO : 480 Khz sinusoid with lower output voltage, 80 W @ 100 E
” MACRO : 480 Khz sinusoid with higher output voltage, 80 W @ 100 E
” CUT : 480 Khz sinusoid with high output voltage, 150 W @ 100 E

” Power Deviation : less than 15% or 5 watts, whichever is greater
” Dimensions (L X W X H) : 400 x 330 x 120 mm
” Weight : < 7 kg " Power supply : 180 - 270 Vac , 50/60 Hz " Max. Power Input : 1000VA, Fuse: 5APatient Electrode monitoring System (Resistance range) : " Dual area PREM patient return Electrode : 10 - 135 ohms " Single Patient Return electrode : < 20 ohms
